50 Amp Transfer Switch 120/240
50 Amp Transfer Switch 120/240[X]
50 Amp Transfer Switch 120/240VAC
Item # 7025350
Mfg No: ATS503
Mfg: AP Products
manufacture logo
50 Amp Generator Switch - This switches power from shoreline to generator simply by starting the generator, it is automatic, No manual switching required. Features include: Generator switching delay, averaging 20 seconds, allows generator to stabilize before connection to load. Generator command with DC coils for voltage stability under low line voltage conditions. UL listed, Quality components ensure reliable, smooth power transfer performance. Installation applications allow for both 30 and 50 amp service. 70 amp neutral capability is available for In-Phase generators with the (supplied and installed) jumpers installed. Metal chassis provides unmatched safety and long term protection for power service selection. Not ignition protected. Suitable for rated outputs not larger than 240 Volt AC, 50 Amps per pole, 4 poles. Dimensions: 6-1/4 inch x 3-3/4 inch x 7-1/2 inch.

Summary

Item Description


ATS503 VAC 50 Amp Generator Switch - This switches power from shoreline to generator simply by starting the generator, it is automatic, No manual switching required. Features include: Generator switching delay, averaging 20 seconds, allows generator to stabilize before connection to load. Generator command with DC coils for voltage stability under low line voltage conditions. UL listed, Quality components ensure reliable, smooth power transfer performance. Installation applications allow for both 30 and 50 amp service. 70 amp neutral capability is available for In-Phase generators with the (supplied and installed) jumpers installed. Metal chassis provides unmatched safety and long term protection for power service selection. Not ignition protected. Suitable for rated outputs not larger than 240 Volt AC, 50 Amps per pole, 4 poles. Dimensions: 6-1/4 inch x 3-3/4 inch x 7-1/2 inch.

Specifications

There are no specifications listed at this time. Please check again for additional updates in the future

Q & A

There are currently no questions listed for this item.


Videos

There are no videos listed at this time for this item.

Photos

All images list for this item: (hover over image for larger image)

thumbnail image of the product
50 Amp Transfer Switch 120/240
 thumbnail image of the product
50 Amp Transfer Switch 120/240
